Fiber Optic Cable Connector Color Scheme

Fiber optic splice closure knowledge brief Published 31 Mar 2021

Prepared for preliminary research by the RIVO OPTICAL knowledge desk. Confirm cable count, splice capacity, sealing class, tray layout, protection sleeves and installation requirements against current standards and product documentation.

Fiber optic connector colors indicate fiber type and polish: blue for UPC, green for APC, and multimode fibers use beige, aqua, or violet depending on the OM standard.Connector Color Codes

Fiber optic connectors use standardized colors to indicate fiber type and polish:

  • Blue connectors: Single-mode fiber with UPC (Ultra Physical Contact) polish, flat endface, low insertion loss, used in data networks and patch panels .
  • Green connectors: Single-mode fiber with APC (Angled Physical Contact) polish, 8-degree angled endface to reduce back-reflection, commonly used in FTTH, PON, and CATV applications .
  • Beige connectors: Legacy multimode fibers OM1/OM2, typically 62.5/125 µm or 50/125 µm cores, used in older LANs .
  • Aqua connectors: Multimode OM3/OM4, optimized for VCSEL lasers and high-speed short-range data transmission, matching the aqua jacket color .
  • Violet connectors: High-performance OM4 variant in some manufacturers, indicating enhanced bandwidth .
  • Lime connectors: OM5 multimode fiber, designed for wideband applications .
Fiber Color Sequence Inside Cables

For individual fibers within a cable, the TIA/EIA-598-C standard defines a 12-color sequence for identification:

  1. Blue
  2. Orange
  3. Green
  4. Brown
  5. Slate
  6. White
  7. Red
  8. Black
  9. Yellow
  10. Violet
  11. Rose
  12. Aqua For cables with more than 12 fibers, the sequence repeats with stripes or markers to distinguish groups . In high-density MPO connectors (16 fibers), additional colors are used: 13: Olive, 14: Magenta, 15: Tan, 16: Lime .
Practical Guidelines
  • Always match connector colors when mating: green to green (APC), blue to blue (UPC). Never mix APC and UPC .
  • Jacket colors also indicate fiber type: yellow for single-mode, orange for OM1/OM2, aqua for OM3/OM4, violet for high-performance OM4, lime for OM5 .
  • Connector boots and adapters follow the same color scheme to maintain consistency across patch panels, splice trays, and distribution hubs . Using these color arrangements ensures correct fiber identification, reduces miswiring, and maintains signal integrity in both single-mode and multimode networks.
