Single-mode fiber LCST dual-core

Fiber optic splice closure knowledge brief Published 16 Sep 2020

Prepared for preliminary research by the RIVO OPTICAL knowledge desk. Confirm cable count, splice capacity, sealing class, tray layout, protection sleeves and installation requirements against current standards and product documentation.

A single-mode LCST dual-core fiber is a duplex optical cable with a 9/125 µm single-mode core, terminated with LC and ST connectors, designed for long-distance, high-speed data transmission.Overview

A single-mode fiber carries light in a single transverse mode, allowing minimal signal loss and high bandwidth over long distances. The core diameter is typically 9 microns, with a cladding diameter of 125 microns, which ensures precise light propagation and low dispersion . Single-mode fibers are ideal for telecommunications, data centers, and long-haul networks.

Dual-Core (Duplex) Configuration

The term dual-core or duplex refers to a fiber cable containing two separate cores within the same jacket. This allows simultaneous bidirectional communication, effectively doubling the data throughput compared to a single-core fiber . Each core can transmit or receive signals independently, making it suitable for high-speed networking applications.

LC and ST Connectors
  • LC (Lucent Connector): A small form-factor connector that provides precise alignment and low insertion loss, commonly used in modern high-density network equipment .
  • ST (Straight Tip/Bayonet Connector): A traditional connector with a twist-lock mechanism, widely used in legacy systems and industrial networks . An LCST dual-core cable has an LC connector on one end and an ST connector on the other, providing flexibility for connecting different types of network devices.
Performance and Standards
  • Fiber Type: Single-mode (OS2 or G.652 standard)
  • Core/Cladding: 9/125 µm
  • Insertion Loss: Typically ≤0.2 dB
  • Return Loss: Typically ≥50 dB
  • Jacket Options: PVC (OFNR) or LSZH for fire safety
  • Transmission Distance: Supports long-haul communication, often several kilometers without repeaters
Applications
  • High-speed data networks in telecommunications and enterprise environments
  • Data centers requiring duplex connections for servers and switches
  • Industrial networks where mixed connector types (LC/ST) are needed
  • Long-distance fiber links where low signal loss is critical In summary, a single-mode LCST dual-core fiber combines the advantages of single-mode transmission, duplex communication, and flexible connector compatibility, making it a reliable choice for high-performance, long-distance optical networks .
