How to connect the MPO optical module

To connect an MPO to an optical module, use a female MPO patch cord to mate with the module's MPO port, ensuring correct polarity and matching end-face type, often via an MPO adapter for backbone cabling.Understanding MPO Connectors and Optical Modules

An MPO (Multi-Fiber Push-On) connector is a high-density fiber optic connector that integrates multiple fibers in a single ferrule, typically 12, 16, or 24 fibers, and is used in parallel optics applications for high-speed data transmission . Inside an optical module (e.g., 40G-SR4 or 100G-SR4), the MPO interfaces with the MT ferrule, connecting the laser/photodiode array to the external fiber . MPO connectors come in male (with guide pins) and female (without guide pins); modules usually have male ports, so the patch cord must be female to avoid damaging the fibers .

Steps to Connect an MPO to an Optical Module
  1. Select the Correct MPO Patch Cord
    • Choose a female MPO patch cord that matches the module's fiber count (e.g., 12-core for 40G/100G SR4 modules).
    • Ensure the end-face type matches the module: UPC (0° flat) or APC (angled) .
  2. Check Polarity
    • MPO connections require proper polarity management to ensure transmit (TX) fibers align with receive (RX) fibers.
    • Two common methods:
      • Method 1: Use Type A backbone cables with Type A MPO adapters, connecting one Type A and one Type B patch cord to the module .
      • Method 2: Use all Type B patch cords and adapters, which simplifies polarity management and is often preferred .
  3. Use an MPO Adapter if Needed
    • MPO adapters hold two connectors together and align the MT ferrules via guide pins, ensuring precise fiber alignment .
    • Select the adapter type (A, B, or C) according to your network's polarity scheme.
  4. Connect the Patch Cord
    • Insert the female MPO connector into the module's MPO port.
    • If connecting through a backbone cable, plug the other end into the MPO adapter, ensuring the key orientation matches the polarity plan .
  5. Verify Connection
    • Check that the fibers are correctly aligned and that the module recognizes the link.
    • Avoid bending the MPO cable sharply and ensure the connector is clean to prevent signal loss.
Additional Tips
  • MPO-MPO jumpers are commonly used for direct module-to-module connections in high-density environments .
  • MPO-LC fanout cables are used when connecting parallel modules to multiple duplex modules (e.g., QSFP+ to SFP+), .
  • Always follow TIA-568 fiber color codes and manufacturer guidelines for fiber numbering and polarity . By following these steps, you can safely and efficiently connect an MPO to an optical module while maintaining proper polarity and minimizing insertion loss.
