100Mbps Single-Mode Optical Module Functions

Fiber optic splice closure knowledge brief Published 22 Apr 2024

Prepared for preliminary research by the RIVO OPTICAL knowledge desk. Confirm cable count, splice capacity, sealing class, tray layout, protection sleeves and installation requirements against current standards and product documentation.

100Mbps single-mode optical modules, such as 100BASE-LX SFP transceivers, are designed for long-distance fiber links exceeding 2 km.Overview

100Mbps single-mode optical modules are Fast Ethernet SFP transceivers that convert electrical signals into optical signals for transmission over single-mode fiber (SMF). They are ideal for long-distance connections, typically beyond 2 kilometers, and are commonly used in enterprise networks, industrial setups, and legacy system upgrades. Single-mode modules offer low signal attenuation and high bandwidth potential, making them suitable for campus backbones and inter-building links .

Common Standards
  • 100BASE-LX: Operates at 1310nm wavelength, supports distances up to 10 km over single-mode fiber, and uses duplex LC connectors. It is the most widely used 100Mbps single-mode standard .
  • 100BASE-EX: Designed for extended reach, typically up to 40 km, also using 1310nm wavelength and duplex fiber .
  • 100BASE-LH: Similar to LX but optimized for longer distances, often up to 70 km in some implementations .
Example Modules
  • StarTech MSA 100BASE-LX SFP: Hot-swappable, MSA-compliant, supports DDM for monitoring optical power and temperature, compatible with most routers and switches .
  • LINK-PP 100M Single-Mode SFPs: Budget-friendly modules compatible with major OEMs, supporting distances from 2 km to 10 km, ideal for network upgrades without replacing existing fiber infrastructure .
Key Features to Consider
  • Wavelength: Typically 1310nm for single-mode 100Mbps modules.
  • Distance: Choose based on your fiber link length (2–10 km for LX, up to 40 km for EX).
  • Duplex Type: Most single-mode modules are dual-fiber (duplex), with one fiber for transmit (Tx) and one for receive (Rx).
  • Device Compatibility: Ensure the module is compatible with your switch or router to avoid network issues.
  • Digital Diagnostics Monitoring (DDM): Provides real-time monitoring of optical power, temperature, and voltage for network reliability.
Applications
  • Connecting buildings on a campus or industrial site.
  • Extending network reach beyond copper cabling limitations.
  • Upgrading legacy Fast Ethernet networks to fiber without replacing existing infrastructure. By selecting the appropriate 100Mbps single-mode optical module, you can achieve reliable long-distance connectivity while maintaining network performance and minimizing costs .
