Common Colors of Fiber Optic Patch Cords

Fiber optic splice closure knowledge brief Published 11 Sep 2020

Prepared for preliminary research by the RIVO OPTICAL knowledge desk. Confirm cable count, splice capacity, sealing class, tray layout, protection sleeves and installation requirements against current standards and product documentation.

Fiber optic patch cords use standardized colors for jackets, connectors, and individual fibers to identify fiber type and ensure proper installation.Outer Jacket Colors

The outer jacket of a fiber optic patch cord indicates the type of fiber inside:

  • Single-mode fiber (SM): Yellow
  • Multimode fibers:
    • OM1: Orange
    • OM2: Orange or black
    • OM3: Aqua
    • OM4: Aqua or violet
    • OM5: Lime green These colors help technicians quickly identify the fiber type in installations and maintenance tasks .
Connector Colors

Fiber connectors also follow a color code to indicate type and polish:

  • Single-mode UPC: Blue
  • Single-mode APC: Green
  • OM1 connector: Beige or grey
  • OM2 connector: Black
  • OM3 connector: Aqua
  • OM4 connector: Violet
  • OM5 connector: Lime green The distinction between UPC and APC connectors is critical because APC connectors have an angled end face (8°) to reduce back reflection, while UPC connectors are flat-polished .
Internal Fiber Colors

Inside the patch cord, each fiber is color-coded for identification, typically in a 12-color sequence:

  1. Blue
  2. Orange
  3. Green
  4. Brown
  5. Slate (Gray)
  6. White
  7. Red
  8. Black
  9. Yellow
  10. Violet
  11. Rose (Pink)
  12. Aqua For cables with more than 12 fibers, the sequence repeats with additional markings, such as stripes or rings, to differentiate groups of fibers . This system ensures accurate splicing, patching, and troubleshooting in high-density fiber networks.
Summary

Using standardized colors for jackets, connectors, and internal fibers allows for quick identification, reduces errors, and improves efficiency in fiber optic network installation and maintenance. Combining color coding with printed labels on the patch cord further enhances clarity and reliability .
